Selcon Actuator

4CH 3A Leading Edge Dimming Actuator supports AC220V and AC110V power input. It has 4 output channels and each channel has a bypass button for manual control. Fuse protection is available for each channel, so that the dimmer will be protected in case of short circuit. LED indicators are available for indicating whether a short circuit occurs in the channel.

Categories: Actuators, HL-BUS

Description

Description

Working voltage ：15~30V DC
Working current ：28mA/24V DC
Input voltage ：AC100-240V (50/60Hz)
Output channel ：4CH/3A
Maximum total output current ：10A
Fuse ：8A aR type
Dimming mode ：TRIAC, minimum load 40W
Dimming curves ：Linear, 1.5 exponent, 2.0 exponent, 3.0 exponent

External Environment
Working temperature ：-5℃~45℃
Working relative humidity ：≤90%
Storage temperature ：-20℃~60℃
Storage relative humidity ：≤93%
Specifications
Dimensions ：144mm×90mm×64mm
Net weight ：715g
Housing material ：Nylon, PC
Installation ：35mm DIN rail installation
Protection rating (Compliant with EN 60529) ：IP20
